Dominator UD Overview
Mid-drive power done right. The Rambo Dominator UltraDrive uses a high-torque mid-drive motor to handle the kind of terrain that breaks lesser bikes: steep grades, loose rock, deep timber. Built for hunters who take backcountry seriously and need a bike that performs like their boots. This is the machine for the hardest miles.
The Bafang Ultra Drive reads how hard the rider is pushing, not just whether the pedals are turning, and puts 160Nm of torque through a SRAM NX 11 speed drivetrain. A RockShox rear shock and an RSK air fork carry it over the rough ground on Maxxis Minion 26 x 4.0 fat tires.
Bafang Ultra Drive 1000W Torque Sensing
The Bafang Ultra Drive 1000W is a high-performance mid-drive motor designed for e-bikes, especially for mountain biking, commuting, and off-road use. The 1000W output offers robust power, which makes it capable of tackling steep hills and challenging terrain with ease. Pair that with 160Nm of torque, providing strong acceleration and assistance on climbs, even with heavier loads. Unlike many other motors that rely on cadence sensors (sensing only if you are pedaling), the Ultra Drive's torque sensor detects how hard you are pedaling, providing smoother and more intuitive power delivery that feels natural.
Full Suspension Smooth Ride
The RockShox RL provides a smooth and consistent rear end feel, which balances well with the stiffness and strength of the RSK air fork. This setup can work especially well for riders who want responsive front end handling paired with predictable rear shock performance.


Bafang Ultra Drive 1000W
Bafang Ultra Drive 1000W torque sensing motor. 1632 peak rating, 160Nm of torque, 1000W nominal power.

48V 15Ah
48V 15Ah 720Wh with LG branded cells. Up to 65 miles on the standard battery, up to 98 miles using the 30Ah upgrade.

Tektro HD-E740 4 piston 203/180
Extreme Duty Tektro HD-E740 4 piston 203/180 hydraulic with electric safety cutoff and special noise reduction pad.

SRAM High-End NX 11 speed
SRAM High-End NX 11 speed with 420% range.

Adjustable Class System
Featuring Adjustable Class System (ACS) and waterproof.

Maxxis Minion 26" x 4.0" fat tires
All Terrain Maxxis Minion 26 x 4.0 Aggressive Tread Tire with Anti Puncture Technology.
| Motor | Bafang Ultra Drive 1000W torque sensing motor |
|---|---|
| Performance | 1632 peak rating, 160Nm of torque, 1000W nominal power. |
| Battery | 48V 15Ah 720Wh with LG branded cells UPGRADE: 20Ah R127-20 OR 30Ah R127-30 battery. Take your travel to the next level. Increase your total range by up to 65 miles using Pedal Assist or 32 miles with throttle only. |
| Range | Up to 65 miles on the standard battery, up to 98 miles using the 30Ah upgrade. |
| Speed | Up to 32mph. |
| Drive Type | Mid-Drive |
| Throttle | Powered by the push of your thumb on the right side throttle |
| Brakes | Extreme Duty Tektro HD-E740 4 piston 203/180 hydraulic with electric safety cutoff and special noise reduction pad |
| Gear System | SRAM High-End NX 11 speed with 420% range. |
| Tires | All Terrain Maxxis Minion 26 x 4.0 Aggressive Tread Tire with Anti Puncture Technology UPGRADE: Tannus Armor. Don’t live in fear of flat tires. Tannus Armous is proven to eliminate 90% of all punctures by providing a layer of protection between the tube and the ground. |
| Chain | KMC Branded X9e. Specially made for high-performance E-Bike power. |
| Frame | Hydroformed aluminum alloy 6061 T6 heat treated, tig welded to the highest specifications |
| Display | Featuring Adjustable Class System (ACS) and waterproof |
| Seat |
UPGRADE: Cloud 9 Airflow Saddle Seat. Ultra wide, thick padding and built for extra-long rides across trails or tough terrain, this seat is the top recommendation from hunters. UPGRADE: Cloud 9 Sport. Designed with memory foam comfort and to keep you in pursuit of your passion longer than ever before. |
| Pedals | Extra wide Wellgo aluminum alloy UPGRADE: Extra Wide pedals equipped with gripping traction pins to keep your feet in place as you tackle the toughest terrain. Snow, mud, and rocky ground are no match for these pedals. |
| Load Capacity | 350 lbs. |
| Weight | 68lbs. with battery removed. Battery weight 11lbs. |
WHAT'S IN THE BOX
NEW Bike
Display
Battery
Charger
Support
Manual
Questions before buying
Is it street legal?+
It ships with Rambo's Adjustable Class System in the display, so the rider can cap the bike at Class 1, 2 or 3 limits. Unrestricted it will do up to 32 mph. Class rules are set locally, so check what your state and your trail system allow before you ride.
15Ah, 20Ah or 30Ah, which battery should I pick?+
Rambo rates the standard 48V 15Ah (720Wh) at up to 65 miles and the 30Ah upgrade at up to 98 miles. Rambo publishes no separate figure for the 20Ah. Those are pedal assist figures. Throttle only riding, steep climbs, heavy loads and cold weather all pull the real number down. Choose it in the Battery Size option above.
Dominator UD or Dominator HD, what is the difference?+
Both are 1000W Bafang mid drives with 160Nm of torque. The UD runs the Bafang Ultra Drive with a torque sensor that reads how hard the rider is pushing, so the assist feels more natural. The HD runs the Bafang BBSHD, which reads pedal cadence. The UD also steps up to a SRAM NX 11 speed drivetrain (the HD has a Shimano 9 speed), Tektro HD-E740 4 piston brakes and Maxxis Minion tires. The compare table below shows the two side by side.
What is the suspension?+
Full suspension. A RockShox RL rear shock works with an RSK air fork up front. Rambo does not publish travel figures for either.
What are the brakes?+
Tektro HD-E740 4 piston hydraulic brakes on a 203mm front rotor and a 180mm rear, with an electric safety cutoff that stops the motor the moment you pull a lever, and noise reduction pads.
How much can it carry, and how much does it weigh?+
Load capacity is 350 lbs, rider and gear together. The bike is 68 lbs with the battery removed, and Rambo lists the battery at 11 lbs. Take the pack out before lifting it onto a rack.
How much assembly is needed?+
Rambo ships the bike almost fully assembled. Final setup takes a few minutes and needs no specialty tools.
Dominator UD on video
Produced by Rambo Bikes. Videos play here on the page.
The Dominator UltraDrive Ebike! Ultimate Power for any Hunter
The Dominator UD in the field: the Ultra Drive motor and full suspension on hunting ground.
The 2024 Dominator UD from Rambo Bikes
Rambo's walk around of the Dominator UD, the full suspension bike its customers asked for.
HD vs Ultra Drive Motor: Which is Right for You?
Rambo explains the difference between the HD's BBSHD and the UltraDrive's torque sensing motor.
