Electric Bike Company Model A E-bike Ideal For Low-Key E-Cruising Around Town

Ideal for low-key e-cruising around town, the Chopper has longer, U-shaped handlebars and a comfortable seat with a backrest. Classic cruiser style with suspension fork for a comfort ride, the EBC Chopper features both the crossbar and battery on the down tube frame to consolidate the center of gravity.

Designed for our Big and Tall riders, the Chopper is a king-sized chariot for those that need a little extra space, length, and support. The EBC Ready to Ride Chopper model is available in Black with leather grips, large round front light and back lights, rear rack and the MIK plate for seamless cargo additions, and 26-inch wheel size. Awarded top rated E-Cruiser in USA by Electric Bike Report.

FEATURES:

Seat Options

EBC’s high-density foam seats are composed of 300 x 300 x 100mm thick foam for superior comfort. Back bumpers add additional cushion and support. Chopper style seats available with extra back support, allow for a more comfortable riding experience for taller riders.

Grip Options

Choose either EBC’s hand stitched leather grips with aluminum secure ends or EBC’s new rubber cushion grips with palm support. Both options include secure aluminum ends to prevent slippage and a jamming of the throttle.

LCD Color Display

A multi-level, compact, user-friendly, LCD color screen is equipped with a convenient USB port for charging phones, playing music, and more. Optional upgraded LCD screen requires riders to accept the Terms and Conditions of usage prior to every ride.

Plug Play

EBC’s patent pending, waterproof wiring system couldn’t be easier. Match the colors and you’re good to go! Developed for ease of replacement, maintenance, and service.

Throttle Options

Optional Thumb or Half-Twist throttle. For those that prefer a safer throttle, the thumb throttle is an ideal choice. For those that are used to operating a motorcycle, the half-twist throttle is a great fit.

Brakes to STOP

Safest e-bike braking system worldwide, by far. TEKTRO Dorado hydraulic disc brakes with sensor control design, motor disconnect, and a four piston brake caliper, allow for single finger braking. The 180mm rotors come standard with stainless steel attachment hardware for extra safety and stopping power.

Double-Up on Lights

Every EBC bike comes with integrated front and rear safety lights. Front baskets also include EBC’s integrated lighting system.

Chain Ring Cogs

Ideal gearing considerations for cruiser style riding is a front 58T chainring / 18T for the rear. This enables the rider to navigate flat, medium, and hilly terrain. Every EBC e-bike is built with stainless steel chainrings and chains, as well as sealed bearing bottom brackets to increase the longevity of the bike.

Suspension Seatpost Options

A must-have accessory for any e-bike rider looking for the ultimate in comfort, the EBC and Satori Suspension Seatposts have been engineered, tested, and built to provide years of comfort and performance. The unique design allows for small bump compliance with a total of 50 mm travel distance. The Satori seatpost coil spring provides just the right amount of compression and rebound damping (alleviating back pain and saddle soreness), and the preload can be easily adjusted to the rider's weight.

Premium Puncture Resistant Tires

Puncture resistant tires are the go-to tire of choice for e-bike riders. EBC’s premium puncture resistant, streamlined tires offer a sleek appearance and are compatible with our Rhino tire size 26″ x 3″ or 24″x3”. Inverted tread design and knurled tread are low profile and fast rolling. Durable and comfortable, they provide a smooth ride. Available in black and brown.

Go Further With Our Batteries

EBC designs and engineers its own battery pack, prioritizing performance and safety. EBC uses certified, tested and internationally approved, quality, lithium Ion NMC battery cells. They come with our best-in-class 2-year warranty. Optional external Supercharger available for Models C and S, standard on all other models. EBC’s plug and play wiring system allows for uncomplicated battery exchange, maintenance, and service.

Drivetrain Sensor Options

Choose between a 12 mag cadence sensor or a torque sensor. A cadence sensor enables direct output on the motor while a torque sensor provides range on the output, giving the rider a more natural feel during riding.

BEST motor in the world

EBC motors include the highest quality copper and neodymium magnets to ensure quiet, efficient output, along with sealed bearings and state of the art circuitry. Designed by our in-house team of experts to make climbing hills efficient and carrying cargo effortless, the powerful high torque, geared hub motor provides zip when you need it. Max speed up to 28 mph*; 10-year warranty. *Factory settings 20mph Throttle / 20mph PAS (Can re-program to 28 mph PAS once confirmed with local city regulations.

Premium rims for higher speed

Since e-bikes are faster, get more use than regular cruisers, and often carry more cargo, EBC installs motorbike-grade, double walled, aluminum 2″ wide e-bike rims. Our premium, high quality rims ensure safety standards are always met.

Stainless Steel Hardware

EBC bikes include 100% stainless steel, rust-resistance and corrosion-free hardware and integrated bearings. Our wheels are built, tested, and inspected in house to ensure longevity. EBC utilizes 13-gauge stainless steel, non-rust spokes and brass corrosion free nipples in front and rear wheel construction. Our state-of-the-art wheel truing machine ensures perfect wheel alignment and balance.

SPECIFICATIONS:

MODEL

Model A

MOTOR

10 year warranty 500w nominal 750w programmed max output due to regulation 1250w max output possible

BATTERY

a. 60 Miles (14 Ah) EBC approved and certified Lithium-Ion NMC Cells (2 year warranty*) * Please see warranty information

CHARGER

2.5 Amp Smart Super Charger with Smart charging technology, cooling fan, aluminum cover & 3 prong charging port for safety

BRAKES

2 Piston, Hydraulic Disc Brakes, 180 mm Stainless steel (1.8 mm thick) Comfort grip levers with motor cutoff safety sensor

CHAIN

Stainless Steel, Durable, Rust Resistant, Low Maintenance Patented Weather Coating

DRIVETRAIN

58T Chainring Sealed bearings for durability, low maintenance and safety over time Engineered specifically for ease of rider operation, 5 Power Assist Levels

FORK

Suspension fork with hydraulic lockout and preload adjustment, turn lockout on at anytime while riding, 80 mm travel

GRIPS

Hand-Stitched Leather

HANDLEBARS

Chopper Style

KICKSTAND

Motor Bike Grade, Heavy Duty Non-slip sole & wide reinforced rubber foot prevents slipping and sinking

LCD SCREEN

Multi Level, user friendly, Interactive, Color LCD Display with USB Charging Port for phone and other accessories

LIGHTS

Front and Rear LED safety lights standard,

PEDALS

Large platform with comfort non-slip rubber with sealed bearings and dual reflectors

WHEELS

Build in our factory - Dished, Trued and Tension perfectly ensuring efficient tracking, safety and range. Double Walled Rims, Stainless Resistant 13G Spokes, Brass Nipples, Sealed Bearings in Hub

SEAT

Chopper seat. Large super comfortable, high density foam with back bumpers for support and comfort.

STEM

Material: Alloy Stem Length: 120mm Bar clamp diameter: 25.4mm Quill: 25.4 x 180mm Adjustability: 0 - 60 degrees

TIRES

Puncture Resistant, Reflective Side Walls with All weather rust proof Schrader valve - Wheel Size 26x2.35"

THROTTLE

Thumb Throttle

TOP SPEED

*Factory settings 20 mph throttle and 20 mph PAS (Can re-program to 28 mph PAS once confirmed with local city regulations.

SENSORS

Cadence sensor

PEDAL ASSIST

Level 1-5

FRAME

Aluminum 6061, Hydro-formed frame

WEIGHT

53lb

WEIGHT LIMIT

420lb

BOTTOM BRACKET

124.5mm alloy cups, double snap seals for water and dirt protection

CRANKSET

56T Alloy Chainring + 170 mm Crank in Alloy 1/2'" x 3/32 for multispeed w/o chainguard

REAR COG

16 rear cog

RIM

Multiple Freewheel. 14-28 Tooth 26" × 2" rim, double wall, 36 hole "13G stainless steel

SPOKES

36 spokes per rim

TUBES

Heavy Dutv Schrader E-Bike Inner Tube, 26"x 2.125"

HUBS

36 spoke hole, front wheel hub sealed cartridge bearings. 9mm quick release, 100mm axle 6 bolt disk rotor compatible

SEATPOST

30.4mm x 300mm, up to 350lbs

SEAT CLAMP

Quick release

GEOMETRY:

	24" Wheel	26" Wheel
Rear Height	24.6"	26.6"
Headset to Seat Tube	24.6"	25.6"
Seat Clamp to Bottom Bracket	17.6"	17.6"
Seat Clamp to Ground	26.3"	28.3"
Wheel Base	46"	48"
End to End	70.6"	74.6"
Standover Height	30.3"	31"
Recommended Rider Height	5' - 6' 8"	5' 2" - 6' 10"

Ride Testing

	On Throttle	Pedal Assist Level
		1	2	3	4	5
Speed	20 mph	13 mph	17 mph	20 mph	25 mph	28 mph
Range	25 miles	50 miles	43 miles	35 miles	21 miles	17 miles

Data collected by actual ride testing. 170-175lb Rider, Smooth Terrain, No Headwind, No Starting / Stopping. Tires have correct pressure and in good condition.
